Appendix D: M35TQ Mobile Rack Specications
Fan Jumper Settings
This mobile rack can utilize up to four fans. To use each fan, you must congure
both jumpers as instructed below.
Fan Jumper Settings
Jumper Jumper Settings Note
JP61
Closed: With Fan
Open: No Fan
FAN#1
JP62
1-2:With Fan
2-3:No Fan
FAN#1
REV 1.01
SASM35TQ
R
S
UPER
REV 1.01
SASM35TQ
R
S UPER
JP62
JP61
Figure D-4: Fan Jumpers
