A-1
Appendix A: Chassis Cables
Appendix A
Cables, Screws,
and other Accessories
A-1 Overview
This appendix lists supported cables for your chassis system. It only includes the
most commonly used components and conî‚¿gurations. For more compatible cables,
refer to the manufacturer of the motherboard you are using and to the Supermicro
Web site at: www.supermicro.com.
A-2 Cables Included with the SC743 Chassis
SC743S1 Series (SCSI)
Part # Type Length Description
CBL-033L-U320 Cable 9" Two-drop SCSI ultra 320 cable
CBL-0087 Cable 20"
Round 16-pin to 16-pin front panel
ribbon cable
CBL-0084 Cable 6" Split converter cable
CBL-0063L Cable 20" SCSI cable
CBL-0062L Cable 7.9"
12V 8-pin to 8-pin power connector
extension cable
CBL-0209L Cable
8.26"
(210mm)
4-pin to 3-pin fan power cable
SC743S2 Series (SCSI)
Part # Type Length Description
CBL-033L-U320 Cable 9" Two-drop SCSI ultra 320 cable
CBL-0087 Cable 20"
Round 16-pin to 16-pin front panel
ribbon cable
CBL-0084 Cable 6" Split converter cable
CBL-0063L Cable 20" SCSI cable
CBL-0062L Cable 7.9"
12V8-pin to 8-pin power connector
extension cable
CBL-0209L Cable
8.26"
(210mm)
4-pin to 3-pin fan power cable
