SC743 Chassis Manual
A-2
SC743i Series
Part # Type Length Description
CBL-0087 Cable 20"
Round 16-pin to 16-pin front panel
ribbon cable
CBL-0084 Cable 6" Split converter cable
CBL-0209L Cable
8.26"
(210mm)
4-pin to 3-pin fan power cable
CBL-0216L Cable
8.26"
(210mm)
4-pin to 4-pin fan power cable
(optional)
SC743TQ Series (SATA/SCSI)
Part # Type Length Description
CBL-0044L Cable 2' SATA cable (Amphenol)
CBL-0087 Cable 20"
Round 16-pin to 16-pin front panel
ribbon cable
CBL-0084 Cable 6" Split converter cable
CBL-0157L Cable 15.8"
8-pin to 8-pin ribbon cable for
SGPIO (supports up to 4 drives)
CBL-0216L Cable
8.26"
(210mm)
4-pin to 4-pin fan power cable
SC743T Series (SAS/SATA)
Part # Type Length Description
CBL-0044L Cable 2' SATA cable (Amphenol)
CBL-0087 Cable 20"
Round 16-pin to 16-pin front panel
ribbon cable
CBL-0084 Cable 6" Split converter cable
CBL-0062L Cable 7.9"
12V 8-pin to 8-pin power connector
extension cable
CBL-0209L; Cable
8.26"
(210mm)
4-pin to 3-pin fan power cable
Note: The SC743T-665 includes the rst three cables above only, plus CBL-0216L
a 200mm, 4-pin to 4-pin middle fan power extension cable
