58 16022904 Rev. 0 ©2004 Maytag Appliances Company
PROGRAMMING PROCEDURES
How to Use the Keypads to Program
the Controls
1. The
Whites & Colors
keypad is used to
change information in the programming codes,
permitting adjustment. Pressing the keypad will
change the characters by one (1). Rapid
adjusting is possible by holding the keypad
down.
2. The
Permanent Press
keypad will advance you
through the programmed codes. Holding the
keypad down will automatically advance through
programs at a rate of one (1) per second.
3. The
Delicates
keypad is used to select or
deselect options. This is an
"OFF"
or
"ON"
selection.
START OPERATING SET-UP
PD and PS Models (Single Load Dryer): Insert
access door key, turn, and lift to remove access
door.
PD Models (Stacked Dryers): Insert access panel
key and turn.
PN Models: Insert service key and turn to
"PROGRAM."
PR Models: Once the debit card reader is installed
(according to the reader manufacturer's
instructions), the set-up mode can be entered by
inserting a manual set-up card (supplied by the
reader manufacturer) into the card slot.
If manual set-up card is not available, manual set-
up mode can be entered by removing connector
AA1 on the circuit board.
CAUTION: The console must not be opened
unless power is first removed from the dryer.
To access connector AA1, remove power, open
console, disconnect plug on AA1, close console,
apply power to dryer. The dryer is now in the set-up
mode.
NOTE:
Before proceeding please note that an
owner can choose to uncrate a new commercial
machine, hook it up, plug it in and have a unit
which operates.
PD units are pre-set at the factory for fixed cycle
price with top off.
PR and PN units are pre-set for free cycle operation
so they can be run without readers or coins.
The appliance is programmed at the factory as
follows:
5 minutes dry time/quarter (Coin 1).
$1.50 dry price (Fixed cycle with top off-PD/
PS models).
$0.00 dry price (Fixed cycle-PR/PN
models).
GENERAL USER INFORMATION
Blank Display: This condition indicates that the
appliance is inoperative.
"0" Minutes Showing in Display: This condition
indicates that the appliance cannot be operated.
Coins dropped during this condition will be stored in
escrow, but cannot be used until normal operation
is restored by opening and closing the door. If the
door switch fails, recovery from this condition is
impossible without service.
Warm Start - After Power Failure: After a delay of
a few seconds, the appliance is restored to the
state that existed at the time of power failure.
"Reselect Cycle" will flash in the display. Select
fabric setting to restart dryer.
Pricing
After the door is opened, following the completion of
a cycle, the display indicates the cycle price (unless
set for free operation). As coins or debit inputs
arrive, the display will change to lead the user
through the intiation of a cycle.
There are four (4) types of pricing.
