Alliance Laundry Systems SWD447C Washer/Dryer User Manual



© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
802702
16
IMPORTANT: Use only a new U.L. listed No. 10
(copper wire only) three or four conductor power
supply cord kit rated 240 Volts (minimum) 30
Amperes and labeled as suitable for use in a clothes
dryer.
Figure 8
Figure 9
D275I
D006I
1 Typical Receptacle
2 Power Cord (Not supplied with dryer)
3 Strain Relief Nut
4 Strain Relief
1
2
3
4
THREE-WIRE
1
2
3
4
FOUR-WIRE
D679I
D680I
NOTE: Dryer is shown with access cover removed for
illustration purposes only. NEVER operate the dryer
with access cover removed.
1 Ground Wire
2 Ground to Neutral Wire
3 Neutral Terminal
4 “L2” Terminal
5 Center Wire (Neutral)
6 Strain Relief (Not supplied with dryer)
7 Ground Screw
8 “L1” Terminal
9 Black Wire
10 White Wire (Neutral)
11 Red Wire
D679I
1
8
7
6
5
4
3
2
THREE-WIRE CONNECTION
D680I
1
8
7
6
10
4
3
1
11
9
FOUR-WIRE CONNECTION
