© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
44
512685
Lint Filter
CLEAN THE LINT FILTER BEFORE DRYING
EACH LOAD. (Refer to Figure 69 for lint filter
location.) Cleaning the lint filter is important because
a layer or pad of lint on the filter will block the flow of
air through the dryer, thus reducing the efficiency of
the dryer. The clothes will take longer to dry and
energy will be wasted.
The lint filter may be washed if needed. Annually
remove lint filter and screw to vacuum the duct under
it.
Figure 69
Motor Overload Protector
The dryer’s motor overload protector stops the motor
automatically in the event of an overload. After
cooling, the overload protector will reset itself. Dryer
can be restarted by pressing the PUSH-TO-START
button or START pad. If overload protector cycles
again, remove the dryer from use and call the service
person to correct the problem.
For Energy Conservation
• Make sure the lint filter is always clean.
• Do not overload dryer.
• Do not overdry clothes.
• Remove items to be ironed while still damp.
• Large loads of similar fabrics dry the most
efficiently. However, dry permanent press in
smaller loads to prevent wrinkling.
• Use the correct temperature FABRIC
SELECTOR setting for the type of fabric being
dried.
• Locate your dryer so the exhaust duct is as short
and straight as possible.
• Do not open the door during the drying cycle.
• Plan to do your laundry on low humidity days;
your clothes will dry faster.
• Should you plan to dry several loads, do them
one after another, then you do not have to reheat
the dryer unit’s interior parts each time.
D608I
1 Lint Filter
D608I
1
