© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
512685
14
Figure 6
Figure 7
H318I
1 NOTE: Where the exhaust duct pierces a
combustible wall or ceiling, the opening must be
3 Clearance per Local Codes
4 No Screen or Cap
sized per local codes. 5 Clean Out Cover
– Inspect Monthly
2 Wall
H318I
2
3
4
EXHAUST
OUTLET
KJIHGFEDCBA
5
30°
1
EXHAUST AIR FLOW
MAXIMUM LENGTH OF DUCT
30 feet (9.1 m)
HORIZONTAL EXHAUST INSTALLATION
AIR
FLOW
D319I
1 Roof
2 Wall
3 2 in. (5 cm) Minimum
4 NOTE: Where the exhaust duct pierces a
combustible wall or ceiling, an opening must
be sized as shown or per local codes.
1
3
4
CONNECT TO DRYER
VERTICAL EXHAUST INSTALLATION
2
To reduce the risk of fire and the
accumulation of combustion gases, DO NOT
exhaust dryer air into a window well, gas
vent, chimney or enclosed, unventilated
area, such as an attic, wall, ceiling, crawl
space under a building or concealed space
of a building.
W045
WARNING
