© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Operation
512685
34
Step 4: Determine Proper Dryer
The direction of the arrow indicates which dryer is
being used.
Step 5: Set Fabric Selector
Select NORMAL for cottons, PERM PRESS/
CASUAL for permanent press, DELICATE for
sensitive items or FLUFF (NO HEAT) for items that
require no heat.
NOTE: Always follow manufacturer’s care label
instructions.
Figure 43
Step 6: Start Dryer
Nonmetered Models
Rotate timer knob to desired time setting (up to
60 minutes). Press the PUSH-TO-START button.
IN USE light will come on (indicating start of cycle).
Figure 44
Coin Slide Models
Place coin(s) in slide and carefully push in as far as
possible and then pull slide out as far as possible. After
IN USE light comes on (indicating start of cycle),
press the PUSH-TO-START button.
Remove knits when slightly damp because overdyring
may cause shrinkage. Do not tumble dry knit woolens.
Should dryer stop before cycle is completed, the motor
overload protector may have cycled. Refer to
Maintenance section.
NOTE: This machine includes an extended tumble
feature. Starting 20 minutes after a cycle ends, the
cylinder will tumble for two minutes every hour
without heat, up to 18 hours or until door is
opened.
DRY2224N
Figure 42
DRY2185N
NO HEATNORMAL
PERM PRESS
CASUAL
FABRIC SELECTOR
DELICATE
DRY2101N
W363I
Figure 45
NONMETERED MODELS
D363I
METERED MODELS
