975ZCK Zero Clearance Kit—For installation into combustible type framing.
976BRK Bedroom Kit—Includes optional thermostat handset and wiring harness (for use in Canada only).
923ACF—Adorn Cast Front.
539 or 549 Cast Iron Arch Fronts—Also require #540WDK Wire Dress Guard, supplied separately.
3336 Closure Plate—For insert installations to cover up to 33” high x 36” wide.
Options
21-1/2” 39” 31”
30-1/4”
38”
34”
923 Adorn 539 Windsor Arch with Plate 549 Windsor Arch no Plate
Choice of Fronts
Note : the 539/549 Fronts require a 540 WDK Wire Dress Guard with the 922 heater.
Cast Iron Tolerances – Due to the nature of Cast Iron, dimensional consistency may vary from one unit to the next
and some variation in surface nish and atness is to be expected. We have done our best to control and make
allowance, however some variation is inevitable.
Closure plates may be required for insert applications where cast fronts do not cover entire openings.
Standard black 33” high x 36” wide closure plate with black aluminum extrusion edge is available.
For installation instructions with Adorn cast front, see Adorn cast front installation section.
For Windsor Arch cast fronts see instructions supplied with individual kit.
