Code Description Part no. Code Description Part no.
1 Drafthood retainer x2 4000166 40 Straight connector 220K891
2 Spigot slide plate assy 4000199 41 Valve mount bracket 4000275
3 Downdraft 4000359 42 Tube nut 420K385
4 Top plate 4000332AH 43 Brick set 4000362
5 Mounting brkt Adorn x2 4000348 44 Brick panel left 4000358
6 Switch plate 4000360 45 Brick panel rear 4000356
7 Cable clamp 4000361 46 Brick panel right 4000357
8 Coal bed support 4000413 47 Coal set 000B245
9A Burner module NG 4000230 48 Front right coal 640K618
9B Burner module LPG 4000164 49 Front left coal 640K617
10 Remote control unit 030A217 50 Centre right coal 640K616
11 Wiring harness 720A556 51 Centre left coal 640K615
12 Remote handset 720A555 52 Base coal 650K237
13 Wall bracket N/A 53 Dressguard - Adorn 450K023
14 Control box 720A554 54 Front casting 4000293AH
15A Burner rail assy NG 3000025 55 Hearth trim casting 230K347
15B Burner rail assy LPG 740K185 56 Crossmember 330A600
16 Air shutter 4000268/3000220 57 Top bafe 4000437
17A Injector elbow NG 82-580 720A580 58 Floor heatshield 4000298AH
17B Injector elbow LPG 92-200 9730013 59 Ash pan door assembly 040A481
18 Olive 8mm 420K342 60 Chrome plated knob 220K993
19 Olive nut 220K567 61 Grommet - foot 620B291
20 Main burner pipe 030A225 62 M5 screw 100D196
21 Spacer angle x2 4000355 63 Ash pan cover painted 550K037AH
22 Ash bed support x2 330A894 64 Outer body 4000474
23 Module plate 4000297 65 Vent adapter 4000473
24 Pilot support bracket 330A904 66 Spacer 4000479
25A Pilot unit assy NG 4000062 67 Heat bafe 4000478
25B Pilot unit assy LPG 4000063 68 Outer top panel 4000477
26 Pilot bracket 720A542 69 Inner top panel 4000476
27 Electrode 720A543 70 Concrete board support 4000490
28 Thermocouple 4000061 71 Inner body 4000475
29 Extended nut 720A200 72 Base 4000472
30 Pilot pipe 030A226
31 Tubing nut 420K385
32 Pilot injector olive 720A196
33A Pilot injector NG #33 720A575
33B Pilot injector LPG #27 720A195
34 Flexible pipe assy 4000345
35 Bypass screw LPG 4000300
36 Control valve GV34 4000056
37 Interruptor block 4000202
38 Vent switch assy 4000366
39 Break off olive nut 220K913
Replacement Parts
