Guide to Names and Functions of Components
Guide to Components
Do not obstruct the machine's vents. Doing so risks fire caused by overheated internal
components.
Exterior: Front view
2 31
4
5
6
7
8
15
14
13
12
11
9
10
CYN001
1. Front cover
Open to access the inside of the printer and remove jammed paper.
Open here to replace the print cartridge and the drum unit.
Guide to Names and Functions of Components
11
