INSTALLATION INSTRUCTIONS
Tools and Parts
Gather the required tools and parts before starting installation. Read and follow the
instructions provided with any tools listed here.
■ Flat-blade screwdriver
■ Adjustable wrench that opens to
1" (2.5 cm) or hex-head socket wrench
(for
adjusting dryer feet)
■ 8" or 10" pipe wrench
■ 8" or 10" adjustable wrench (for gas
connections)
■ Pipe-joint compound resistant to LP gas
■ Pliers
■ Tin snips (new vent installation)
■ Level
■ Vent clamps
■ Caulking gun and compund (for
installing new exhaust vent)
■ Tape measure
■ Knife
Parts supplied:
Remove parts package from dryer drum. Check that all parts were included.
A
A.Leveling legs (4)
Parts needed:
Check local codes. Check existing electrical supply and venting and see “Electrical
Requirements” and “Venting Requirements” before purchasing parts.
Mobile home installations require metal exhaust system
hardware available for purchase from
the dealer from whom you purchased your dryer. For information on ordering, please refer to
the “Assistance or Service” section. You may also contact the dealer from whom you
purchased your dryer.
■ Mobile home installation kit. Ask for Part Number 346764.
■ Metal exhaust system hardware.
Location Requirements
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from dryer.
Place dryer at least 18 inches (46 cm) above the floor
for a garage installation.
Failure to do so can result in death, explosion, or fire.
You will need
■ A location that allows for proper exhaust installation. See “Venting Requirements.”
■ If you are using a power supply cord, a grounded electrical outlet located within
2 ft (61 cm) of either side of the dryer
. See “Electrical Requirements.”
■ A sturdy floor to support the total weight (dryer and load) of 200 lbs (90.7 kg). The
combined weight of a companion appliance should also be considered.
■ A level floor with a maximum slope of 1" (2.5 cm) under entire dryer.
Do not operate your dryer at temperatures below 45ºF (7ºC). At lo
wer temperatures, the dryer
might not shut off at the end of an automatic cycle. Drying times can be extended.
The dryer must not be installed or stored in an
area where it will be exposed to water and/or
weather.
Check code requirements. Some codes limit, or do not permit, installation of the dryer in
garages, closets, mobile homes or sleeping quarters. Contact your local building inspector.
Installation Clearances
The location must be large enough to allow the dryer door to open fully.
