3-22
MS-6763 M-ATX Mainboard
Run VGABIOS if S3 Resume
Selecting [Enabled] allows BIOS to call VGABIOS to initialize the VGA card
when system wakes up (resumes) from S3 sleep state. The system resume
time is shortened when you disable the function, but system will need an AGP
driver to initialize the VGA card. Therefore, if the AGP driver of the card
does not support the initialization feature, the display may work abnormally
or not function after resuming form S3.
Power Management
This item is used to select the degree (or type) of power saving and is related
to these modes: Suspend Mode and HDD Power Down. There are three op-
tions for power management:
Min Saving Minimum Power Management. Suspend Mode=1 Hour
Max Saving Maximum Power Management. Suspend Mode=1 Min
User Define Allows end users to configure each mode separately.
Video Off Method
This determines the manner in which the monitor is blanked.
V/H SYNC+Blank This selection will cause the system to turn off
the vertical and horizontal synchronization ports
and write blanks to the video buffer.
Blank Screen This option only writes blanks to the video
buffer.
DPMS Initial display power management signaling.
Video Off In Suspend
This option enables the monitor to be turned off during the suspend mode.
Settings: Yes, No.
Suspend Type
This setting allows you to select the type of Suspend mode. Setting options:
Stop Grant (saves the state of the entire system to disk and then powers off the
system), PwrOn Suspend (the CPU and core system remain powered on in a
very low-power mode).
MODEM Use IRQ
This determines the IRQ in which the MODEM can use. Activity of the se-
lected IRQ always awakens the system. Settings: 3, 4, 5, 7, 9, 10, 11, NA..
