1-3
Getting Started
On-Board Peripherals
h On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes
- 2 serial ports (COM A & JCOM1)
- 1 parallel port supports SPP/EPP/ECP mode
- 1 VGA port (for 865GM3 Series only)
- 8 USB 2.0 ports (Rear * 4/ Front * 4)
- 1 Line-In/Line-Out/Mic-In port
- 1 RJ45 LAN jack
- 2 IEEE 1394 ports (optional for 865PEM2 Series only)
Audio
h AC97 link controller integrated in ICH5.
h Software audio codec AD1981B.
- Compliant with AC97 v2.2 spec.
- Meets PC2001 audio performance requirement.
- Can support SPDIF Out via bracket only.
LAN
h Intel 82547EI (for 865GM3 Series only)
- Integrated 10/100/1000Mbps Ethernet MAC and PHY in one chip.
- Supports auto-negotiation operation.
- Compliant with PCI v2.2, and LAN on Motherboard (LOM) standard.
h RealTek RTL8101L (for 865PEM2 Series only)
- Integrated 10/100Mbps Ethernet MAC and PHY in one chip.
- Supports 10Mb/s and 100Mb/s auto-negotiation operation.
- Compliant with PCI v2.2, and LAN on Motherboard (LOM) standard.
BIOS
h The mainboard BIOS provides “Plug & Play” BIOS which detects the pe-
ripheral devices and expansion cards of the board automatically.
h The mainboard provides a Desktop Management Interface (DMI) function
which records your mainboard specifications.
Dimension
h Micro ATX Form Factor: 24.38 cm (L) x 24.38 cm (W).
Mounting
h 8 mounting holes.
