TABLE 3A
SERIES 5B INTEGRAL CANOPY DRAFTHOODS - BOILER SIZES
PART SIZE PART NO.
Canopy -
Drafthood No.
BOILER SIZE (QUANTITY)
5006B 5007B 5008B 5009B 5010B
36-1/2 X 25-3/4 61113063 5006B (1) 1
36-1/2 X 31-3/16 61113073 5007B (2) 1
36-1/2 X 36-5/8 61113083 5008B (3) 1
36-1/2 X 41-1/16 61113093 5009B (4) 1
36-1/2 X 47-1/2 61113103 5010B (5) 1
5011B 5012B 5013B 5014B 5015B
36-1/2 X 25-3/4 61113063 5006B (1) 2 1
36-1/2 X 31-3/16 61113073 5007B (2) 1 2 1
36-1/2 X 36-5/8 61113083 5008B (3) 1 2
36-1/2 X 41-1/16 61113093 5009B (4)
36-1/2 X 47-1/2 61113103 5010B (5)
5016B 5017B 5018B 5019B 5020B
36-1/2 X 25-3/4 61113063 5006B (1) 3
36-1/2 X 31-3/16 61113073 5007B (2)
36-1/2 X 36-5/8 61113083 5008B (3) 1
36-1/2 X 41-1/16 61113093 5009B (4) 1 2 1
36-1/2 X 47-1/2 61113103 5010B (5) 1 2 1
5021B 5022B 5024B 5026B
36-1/2 X 25-3/4 61113063 5006B (1) 1 1
36-1/2 X 31-3/16 61113073 5007B (2) 1 2 3 3
36-1/2 X 36-5/8 61113083 5008B (3) 1
36-1/2 X 41-1/16 61113093 5009B (4)
36-1/2 X 47-1/2 61113103 5010B (5) 1 1
