FIG. 1
DIMENSIONAL DATA
Boiler
Size
Jacket
Overall
Length
‘A’
Drafthood Height, Size and Location
Top Supply
and Rear Return
Location
Supply
Conn.
Qty &
Size
Return Conn.
Qty. & Size
Gas Conn.
Size Nat. &
Propane
No. & Dia. of
Flue Outlets
Approx.
Shipping
Weight
(LB.)
‘B’
Dia.
‘C’
Dia.
‘D’
Dia.
‘E’
Dia.
‘F’ ‘G’ ‘H’ ‘J’ ‘K’ ‘M’ ‘N’
5006B 34 9 --- --- --- --- --- --- 17 19-3/4 --- --- (2) 3 (2) 3 1 (1) 9 1160
5007B 39-3/8 10 --- --- --- --- --- --- 19-3/4 32-1/4 --- --- (2) 3 (2) 3 1 (1) 10 1340
5008B 44-3/4 12 --- --- --- --- --- --- 22-3/8 38-3/8 --- --- (2) 3 (2) 3 1 (1) 12 1525
5009B 50-1/4 12 --- --- --- --- --- --- 25-1/8 43-3/4 --- --- (2) 3 (2) 3 1-1/4** (1) 12 1720
5010B 55-3/4 12 --- --- --- --- --- --- 27-7/8 49-1/4 --- --- (2) 3 (2) 3 1-1/4 (1) 12 1895
5011B 61-1/8 9 9 --- --- 27-1/4 --- --- 17 54-3/4 --- --- (2) 3 (2) 3 1-1/4 (2) 9 2085
5012B 66-1/2 9 10 --- --- 29-7/8 --- --- 19-3/4 60-1/8 --- --- (2) 3 (2) 3 1-1/4 (1) 9, (1) 10 2280
5013B 72 10 10 --- --- 32-5/8 --- --- 19-3/4 65-1/2 --- --- (2) 3 (2) 3 1-1/4 (2) 10 2460
5014B 77-1/2 10 12 --- --- 35-3/8 --- --- 22-3/8 71 --- --- (2) 3 (2) 3 1-1/4 (1) 10, (1) 12 2640
5015B 82-7/8 12 12 --- --- 38 --- --- 22-3/8 38-1/4 38-1/4 --- (3) 3 (2) 3, (1) 2-1/2 (2) 1* (2) 12 2870
5016B 88-1/4 12 12 --- --- 40-3/4 --- --- 25-1/8 38-1/4 43-5/8 --- (3) 3 (2) 3, (1) 2-1/2 (1) 1, (1) 1-1/4* (2) 12 3070
5017B 93-3/4 12 12 --- --- 43-1/2 --- --- 25-1/8 43-5/8 43-5/8 --- (3) 3 (2) 3, (1) 2-1/2 (2) 1-1/4* (2) 12 3265
5018B 99-1/4 12 12 --- --- 46-1/4 --- --- 27-7/8 43-5/8 49-1/8 --- (3) 3 (2) 3, (1) 2-1/2 (2) 1-1/4* (2) 12 3445
5019B 104-5/8 12 12 --- --- 49 --- --- 27-7/8 49-1/8 49-1/8 (3) 3 (2) 3, (1) 2-1/2 (2) 1-1/4* (2) 12 3620
5020B 110 9 9 12 --- 27-1/4 38 --- 27-7/8 54-1/2 49-1/8 --- (3) 3 (2) 3, (1) 2-1/2 (2) 1-1/4* (2) 9, (1) 12 3810
5021B 115-1/2 9 10 12 --- 29-7/8 40-3/4 --- 27-7/8 27-3/8 32-5/8 49-1/8 (4) 3 (2) 3, (2) 2-1/2 (2) 1-1/4* (1) 9, (1) 10, (1) 12 4005
5022B 121 10 10 12 --- 32-5/8 40-3/4 --- 27-7/8 32-3/4 32-5/8 49-1/8 (4) 3 (2) 3, (2) 2-1/2 (2) 1-1/4* (2) 10, (1) 12 4185
5024B 131-3/4 9 10 10 10 29-7/8 32-5/8 32-5/8 19-3/4 27-3/8 65-1/4 32-3/4 (5) 3 (2) 3, (3) 2-1/2 (2) 1-1/4* (1) 9, (3) 10 4530
5026B 142-3/4 10 12 10 10 35-3/8 35-3/8 32-5/8 19-3/4 32-3/4 70-3/4 32-3/4 (5) 3 (2) 3, (3) 2-1/2 (2) 1-1/4* (3) 10, (1) 12 4895
* Dual Manifolds - 5015B thru 5026B **1” - USA - EI
NOTE
1.5006BTHRU5014BBOILERSREQUIRE
SINGLE GAS TRAIN LOCATION ON
LEFT END OF BOILER (STANDARD)
GAS TRAIN MAY BE RELOCATED
TO RIGHT END OF BOILER (EXCEPT
5012BAND5014BBOILERS).
2.5015BTHRU5026BBOILERSREQUIRE
DUAL GAS TRAINS.
3. GAS SUPPLY PRESSURE, IN W.C.
NATURAL GAS
MAXIMUM: 14” W.C.
MINIMUM: 5.5” W.C.
 (5009BAND5011BTHRU5014BAND
5020BTHRU5026B)
MINIMUM: 5” W.C.
 (5006BTHRU5008BAND5010B,5015B
THRU5019B)
LP GAS:
MAXIMUM: 14” W.C.
MINIMUM: 11” W.C.
4. WATER BOILERS - MAXIMUM DESIGN
WORKINGPRESSURE:50PSI.
5. STEAM BOILER - MAXIMUM DESIGN
WORKING PRESSURE: 15 PSI.
6.DIMENSIONSININCHES
