Table 4. Audio Interface Signal Description
Table 5. USB Controller Signal Description
Table 6. MutiMediaCard Interface Signal Description
T0 I
Timer 0 External Clock Input
When timer 0 operates as a counter, a falling edge on the T0 pin increments
the count.
P3.4
T1 I
Timer 1 External Clock Input
When timer 1 operates as a counter, a falling edge on the T1 pin increments
the count.
P3.5
Signal
Name Type Description
Alternate
Function
DCLK O DAC Data Bit Clock -
DOUT O DAC Audio Data -
DSEL O
DAC Channel Select Signal
DSEL is the sample rate clock output.
-
SCLK O
DAC System Clock
SCLK is the oversampling clock synchronized to the digital audio data (DOUT)
and the channel selection signal (DSEL).
-
Signal
Name Type Description
Alternate
Function
D+ I/O
USB Positive Data Upstream Port
This pin requires an external 1.5 KΩ pull-up to V
DD
for full speed operation.
-
D- I/O USB Negative Data Upstream Port -
Signal
Name Type Description
Alternate
Function
MCLK O
MMC Clock output
Data or command clock transfer.
-
MCMD I/O
MMC Command line
Bidirectional command channel used for card initialization and data transfer
commands. To avoid any parasitic current consumption, unused MCMD input
must be polarized to V
DD
or V
SS
.
-
MDAT I/O
MMC Data line
Bidirectional data channel. To avoid any parasitic current consumption, unused
MDAT input must be polarized to V
DD
or V
SS
.
-
Signal
Name Type Description
Alternate
Function
