Operation
F232219
10
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Summary of Major Features
Table 1
LED for Machine Functions LED lights inform operator which machine function is active. DOOR LED lights to
inform operator that the door can be opened or should be closed. The circle LED
indicates that the filter needs cleaning.
Water Levels Three (3) – Contacts from pressure switch (test cycle)
Main LED display 4 digit LED display counts down cycle time. Lights in LED display indicate out-of-balance
conditions and, in test cycle, water level. Display shows “01” as the final spin time.
Cycle selection keypads Eight (8) cycle select keypads with LED indicator to show selected cycle. LED lights
will flash to prompt user to press a keypad.
START keypad Press to start a cycle after cycle selection is made. LED light will flash to prompt user to
press keypad.
Test Cycle with “Advance” For troubleshooting. Advance rapidly through test cycle by pressing the UP keypad.
Refer to PROGRAMMING manual.
Fill Temperatures Cold, Hot, Warm
Supplies Five (5) or Four (4) with extra fill value option.
Agitation Types Normal or Gentle
Drain Options Normally open gravity drain
Cycle Count 0 to 9999 cannot be reset – Rolls over after 9999
Rapid Advance Mode Rapid Advance can be enabled or disabled. Enabled allows user to advance through a
cycle. Refer to the Programming Manual.
