Installation
510963
8
Before You Start
Tools
For most installations, the basic tools you will need are:
Figure 1
Exhaust
Use rigid metal duct and exhaust the dryer to the
outside by the shortest route possible.
Figure 2
NOTE: For more detailed information, refer to
Section on Dryer Exhaust Requirements.
Electrical
● ELECTRIC DRYER
Dryer needs a 3 or 4 wire 120/240 or
120/208 Volt, 30 Amp, 60 Hertz, 1 phase
electrical supply.
● GAS DRYER
Dryer needs a 120 Volt, 15 Amp, 60 Hertz,
polarized 3-slot effectively grounded receptacle.
NOTE: For more detailed information, refer to
Section on Electrical Requirements.
If the supply cord is damaged, it must be replaced by a
special cord or assembly available from the
manufacturer or its service agent and is to be replaced
by a qualified service person.
Gas
Dryer is equipped for Natural Gas with a 3/8 inch NPT
gas supply connection. For more detailed information,
refer to Section on Gas Requirements.
Location
Place the dryer on a solid floor with an adequate air
supply. For more detailed information, refer to Section
on Location Requirements.
D818I
1 Wrench
2 Screwdrivers
3 Level
4 Teflon Tape
5 Duct Tape
D314I
1
2
3
4
5
Any disassembly requiring the use of
tools must be performed by a suitably
qualified service person.
W299
WARNING
