Chapter 2: Installation
2-21
JPW2
JPW3
J11
+
LE4
SW1
JPW1
FAN4
FAN8
FAN7
FAN3
FAN1
4
1
FAN2
FAN6
FAN5
JLPC80
JPCIE3
JWD1
JPL1
JPG1
LE1
LE2
JBAT1
JL1
JNMI1
JSPK1
J_UID_OW
PHY
x4 in x16 Slot
SBX 2B
SBX 1B
PCI-E 2.0
SBX 2A
IPMB
T-SGPIO0
IPMI_LAN
USB2/3
SBX 1A
P2 DIMM1A
P1DIMM3A
P2 DIMM1B
P1 DIMM2B
P2 DIMM2A
P1 DIMM2A
P2 DIMM2B
P1 DIMM1B
P2 DIMM3A
P1 DIMM1A
P2 DIMM3B
CLEAR
VGA
COM1
LAN2
LAN1
USB0/1
CMOS
I-SATA1
JPI2C (PWR I2C)
CPU1
CPU2
BIOS
T-SGPIO1
I-SATA2
I-SATA3
I-SATA4I-SATA5
I-SATA6
Intel
ICH10R
(South Bridge)
Intel
5520
IOH-36D
Intel
82576
LAN CTRL
Winbond
450R
BMC
P1 DIMM3B
Front Panel CTRL
Battery
X8DTG-DF
J12
JPCIE1
JPCIE2
A
B
C
A. Fan1
B. Fan2
C. Fan3
D. Fan4
E. Fan5
F. Fan6
G. Fan7
H. Fan8
D
Fan Headers
The X8DTG-DF has eight chassis/system fan
headers (Fan1 to Fan8) on the motherboard.
All these 4-pin fans headers are backward
compatible with the traditional 3-pin fans. 3-pin
fans do not support fan speed control. How-
ever, fan speed control is available for 4-pin
fans. The fan speeds are controlled by Thermal
Management via Hardware Monitoring in the
Advanced Setting in the BIOS. (The Default
setting is Disabled.) See the table on the right
for pin de nitions.
Fan Header
Pin De nitions
Pin# De nition
1 Ground
2 +12V
3 Tachometer
4 PWR Modulation
G
F
E
H
