PCAN-USB Hub – User Manual
3
Contents
1 Introduction 4
1.1 Properties at a Glance 4
1.2 Prerequisites for the operation 5
1.3 Scope of Supply 5
2 Installing the Software and the PCAN-USB Hub 6
3 Connectors on the PCAN-USB Hub 9
3.1 Upstream Port (USB Cable) 9
3.2 Power (Voltage Supply) 9
3.3 CAN 10
3.3.1 Supplying External Devices via the CAN
Connector 11
3.4 RS-232 13
3.5 USB Ports (Downstream) 13
4 Operation 14
4.1 Status LEDs 14
4.2 Removing the Hub Safely 15
5 CAN Software 17
5.1 CAN Monitor PCAN-View for Windows 17
5.2 Linking Own Programs with PCAN-Light 19
6 Technical Specifications 20
Appendix A CE Certificate 22
Appendix B Quick Reference 23
