Chapter 2 PXI-1006 Features
© National Instruments Corporation 2-3 PXI-1006 User Manual
Figure 2-1.
Front View of the PXI-1006 Chassis
Figure 2-2. Rear View of the PXI-1006 Chassis
1 Remote On/Off (Standby) Switch
2 Optional Mounting Brackets
3 Removable Feet
4 Three Controller Expansion Slots
5 System Controller Slot
6 Star Trigger/Peripheral Slot
7 Segment Break 1
8 17 Peripheral Slots
9 Segment Break 2
1 Fan Speed Selector
2 Remote Power Status and Inhibit Connector
3 Chassis Ground Screw
4 Universal AC Input
5 Circuit Breake
