Performance Verification Test Records
Agilent E4411B Performance Verification Test Record
50 Ω, 100 Hz RBW
400 kHz (11)________ –123 dBm
±1.23 dB
1 MHz to 10 MHz (12)________ –123 dBm
±1.23 dB
10 MHz to 500 MHz (13)________ –127 dBm ±1.23 dB
500 MHz to 1 GHz (14)________ –125 dBm
±1.23 dB
1 GHz to 1.5 GHz (15)________ –121 dBm
±1.23 dB
75
Ω, 1 kHz RBW
1 MHz to 10 MHz (21)________ –63 dBmV
±1.23 dB
10 MHz to 500 MHz (22)________ –65 dBmV
±1.23 dB
500 MHz to 1 GHz (23)________ –60 dBmV
±1.23 dB
1 GHz to 1.5 GHz (24)________ –53 dBmV
±1.23 dB
75
Ω, 100 Hz RBW
1 MHz to 10 MHz (29)________ –72 dBmV
±1.23 dB
10 MHz to 500 MHz (30)________ –74 dBmV
±1.23 dB
500 MHz to 1 GHz (31)________ –68 dBmV
±1.23 dB
1 GHz to 1.5 GHz (32)________ –61 dBmV ±1.23 dB
39. Residual Responses Note: Enter data in the appropriate section below depending upon
the input impedance and serial number of the analyzer.
50
Ω, 150 kHz to 1.5 GHz (1)________ –90 dBm ±0.87 dB
75 Ω, 1 MHz to 1.5 GHz (1)________ –36 dBmV ±0.87 dB
41. Tracking Generator
Absolute Amplitude
and Vernier Accuracy
Note: Enter data in the appropriate section below depending upon
the input impedance and serial number of the analyzer.
50
Ω (Option 1DN)
Absolute Amplitude
Accuracy
–0.5 dB (1)________ 0.5 dB ±0.096 dB
Positive Vernier Accuracy (2)________ 0.75 dB
±0.008 dB
Table 3-16 Agilent E4411B Performance Verification Test Record
Agilent Technologies
Model E4411B Report No. ___________
Serial No. ___________ Date ___________
Test Description Minimum
Results
Measured
Maximum
Measurement
Uncertainty
