Installation Instructions
14
ATTACH THE HOSE CONNECTORS
AND ELECTRIC CONNECTORS
Remove 4 protective caps from the rear
of the washer and SmartDispense
™
Pedestal.
Attach the electric connector to the rear
of the washer and the rear of the pedestal.
Press the cord into the protective holders
along the back of the washer.
Attach the hose connector to the rear
of the washer and the rear of the pedestal.
Press all three tubes into the three protective
holders along the back of the washer.
A
B
C
7
FINALIZE THE INSTALLATION
Refer to the washer Installation Instructions
to complete the installation.
8
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Connect the
Quick Connect
Hose to the
back of the
washer
Attach electrical
connector cord
PREFERRED CONFIRMATION
OF INSTALLATION
Fill your detergent tank with liquid HE (High
Efficiency) laundry detergent and softener
tank with concentrated liquid fabric softener.
Set your SmartDispense settings (see page 5
of the Owner’s Manual).
Run a Speed Wash. This will fill your
SmartDispense supply lines with detergent
and/or fabric softener for all active tanks
selected in Step B.
NOTE: If the machine could not run a Speed
Wash, check the following:
1. Screw the hose and electrical connectors in
tightly on the back of the washer and pedestal.
2. Make sure all 3 sensors are plugged into
the connector on the back of the drawer
inside the pedestal.
A
B
C
9
Protective holders
