GE SPBD880 Washer Accessories User Manual



BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT – Save these instructions
for local inspector’s use.
IMPORTANT – Observe all governing
codes and ordinances.
Note to Consumer – Keep these instructions
with your Owner’s Manual for future reference.
Completion time – 1 to 2 hours
Proper installation is the responsibility of the installer.
Product failure due to improper installation is not
covered under the Warranty.
CAUTION – Due to the size and weight
of these products, and to reduce the risk of personal
injury or damage to the product, TWO PEOPLE ARE
REQUIRED FOR PROPER INSTALLATION.
See washer installation instructions for additional
installation requirements and guidelines.
Installation Pedestal
Instructions
Model SPBD880
If you have any questions, call 800.GE.CARES (800.432.2737) or visit our Website at: ge.com
In Canada, call 1.800.561.3344 or Visit our Website at: www.geappliances.ca
12
TOOLS YOU WILL NEED
KIT CONTENTS
4 Mounting Screws
Electric Cord
Phillips Head Screwdriver
9/16 Open-End Wrench
or Adjustable Wrench
8 mm Socket Wrench
INSTALLATION PREPARATION
Remove the packaging.
The Installation Kit is taped at the top of the shipping
carton. Remove the kit and set aside for final installation.
Flatten the product carton to use as a pad to lay
the washer down on its side. Continue using the carton
to protect the finished floor in front of the installation
location.
REMOVE THE LEVELING LEGS
Carefully lay the washer on its side to access
the leveling legs on the bottom of the
appliance.
IMPORTANT: Do not lay the washer on its
back. Do not remove the shipping bolts on
the back side of the washer. The bolts must
remain in place until the washer is returned
to an upright position.
Use an open-end wrench to remove
the washer leveling legs.
1
A
B
Back out and
remove all
4 leveling legs
Quick Connect Hose
