*Please be sure to read and follow the installation operation manual. (Pedestal Model : P-W151W)
People's safety is the first priority.
There are many safety particulars in the guidebook and
product. Therefore, please be sure to read and abide by all
safety particulars.
1. Please take out the height-high shelf and its installation
manual from the wrapped box.
2. Please untie 4 horizontal adjustment legs of the washer
and dryer.
3. Please turn and insert 4 horizontal adjustment legs in the
lower part of adjustable cases.
4. Please place the washer or dryer on the adjustable cases.
N.B : The washer and dryer are heavy so that more than
two persons have to raise them together.
N.B : Please pull out the plugs of the washer and dryer in
use, lock the faucet and divide the supply hose and
drainage hose. Then, please pull out water from all
hoses.
5. After pulling out and opening the drawers of adjustable
cases forwards, pull out the accessory bags for bolts from
the drawersand insert the spring washer (b) and plain
washer (c) into the joint
BOLT (a) in order.
6. In order for the washer or dryer to operate properly the
combination of adjustable cases on the bottom must be
balanced. If the adjustable legs are not balanced due to a
unstable platform, it is needed to balance them by
adjusting the horizontal adjustment legs. And, to fix the
position of these legs, tighten the bolts by using wrench
provided as much as possible. This would result in a
balanced operation.
7. Take out the back cover and screw from the left part of
the height-high shelf drawer.
Assemble 10 svrews at the holes back of the shelf.
8. After transferring it into the desired installation spot, try to
operate the washer or dryer and check whether there are
any mechanial noises and vibration.
N.B : In order for the washer or dryer to be operate the
combination of adjustable cases on the plain
bottom. When they are not at a level with each
adjustment legs of adjustable cases, leave the
horizontal adjustment legs as it is, and fasten the
lock nut towards the cases solidly.
9. After transferring them in the desired installation location,
get the washer or dryer operated and check whether
there are any mechanical noises and vibration.
INSTALLATION OF ACCESSORIES
CAUTION : When installing the said product, please be sure to let the expert with electrictiy & machine related
training and sufficient experiences install it.
Excessive load is dangerous.
In case of installing and carrying the adjustable cases of
the washer and dryer, more than two persons should
do it together. Please let children not play on the cases.
Installation methods
