Installation/Operation Supplement
F232148 (EN)
16
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
135 Pound Capacity Models
Figure 4
R012I
1 Recirculation Port 6 Steam Inlet
2 Extra Fill Valve 7 Drain Outlet
3 Cold Water Inlet 8 Reuse Drain Outlet
4 Vent 9 Main Power
5 Hot Water Inlet 10 External Supply Signal
1
2
3
4
5
6
7
8
9
10
1664 mm
(65 1/2")
1575 mm
(62")
1803 mm
(71")
718 mm
(28 1/4")
768 mm
(30 1/4")
1060 mm
(41 3/4")
1457 mm
(57 5/16")
1491 mm
(58 11/16")
992 mm
(39 3/32")
913 mm
(35 29/32")
952 mm
(37 1/2")
1376 mm
(54 3/16")
1549 mm
(61")
1905 mm
(75")
529 mm
(20 13/16")
1430 mm
(56 5/16")
1435 mm
(56 1/2")
1468 mm
(57 13/16")
584 mm
(23")
1803 mm
(71")
1715 mm
(67 1/2")
1829 mm
(72")
509 mm
(20 1/16")
521 mm
(20 1/2")
171 mm
(6 3/4")
Front Side
Rear
