Installation/Operation Supplement
9
F232148 (EN)
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Table 3 (Continued)
135 Pound 250 Pound
Standard Standard
Forward Tilt
Option
Two-Way
Tilt Option
Cylinder Speeds
1/2 Wash/reverse speed, RPM 26 21 21 21
Wash/reverse speed, RPM 36 31 31 31
Distribution speed, RPM 62545454
Medium extract speed, RPM 170 140 140 140
High extract speed l, RPM 375 340 340 340
High extract speed 2, RPM 480 435 435 435
High extract speed 3, RPM 715 650 650 650
Centrifugal Force Data
1/2 Wash/reverse centrifugal force, Gs 0.412 0.325 0.325 0.325
Wash/reverse centrifugal force, Gs 0.790 0.708 0.708 0.708
Distribution centrifugal force, Gs 2.34 2.15 2.15 2.15
Medium extract centrifugal force, Gs 17.6 14.7 14.7 14.7
High extract 1 centrifugal force, Gs 85.8 86.9 86.9 86.9
High extract 2 centrifugal force, Gs 141 142 142 142
High extract 3 centrifugal force, Gs 312 318 318 318
Balance Detection
Vibration safety switch installed Standard Standard Standard Standard
Direct Steam Heating (Optional)
Steam inlet connection size, mm (in.) DN19 (0.75) DN25 (1.0) DN25 (1.0) DN25 (1.0)
Number of steam inlets 1 1 1 1
Steam required to raise bath temperature
10 °C, kg (10 ° F, lb.)
LOW 3.11 (6.84) 5.23 (11.5) 5.23 (11.5) 5.23 (11.5)
HIGH 4.40 (9.67) 7.91 (17.4) 17.4 (7.91) 17.4 (7.91)
Average steam use per cycle, bhp 4.78 9.0 9.0 9.0
Electric Heating (Optional)
Total electric heating capacity, kW 45 N/A N/A N/A
Number of electrical heat elements 18 N/A N/A N/A
Electrical heat element size, kW 2.5 N/A N/A N/A
Time required to raise bath temperature
10°C, min. (10°F, min.)
LOW 5.0 (3.2) N/A N/A N/A
HIGH 6.4 (4.2) N/A N/A N/A
