Chapter 1: Introduction
1-11
Introduction
ACPI Features
• Microsoft OnNow
• Slow blinking LED for suspend state indicator
• Main switch override mechanism
• External modem ring-on
Onboard I/O
• AIC-7902 for dual channel Ultra320 SCSI
• Adaptec 2010S SCSI RAID support (X5DL8-GG)
• Adaptec 2015S SCSI RAID support (X5DLR-8G2+/X5DLR-8G2)
• Integrated ATI Rage XL Graphics Controller
• Intel 82540EM Gb Ethernet controller (X5DL8-GG - LAN1)
• Broadcom BCM5703 Gb Ethernet controller (X5DL8-GG - LAN2)
• Broadcom BCM5704 dual Gb Ethernet controller (X5DLR-8G2+/X5DLR-
8G2)
• 2 EIDE bus master interfaces support Ultra DMA/100
• 1 floppy port interface (up to 2.88 MB)
• 2 Fast UART 16550A compatible serial ports
• 1 EPP/ECP (Enhanced Parallel Port/Extended Capabilities Port, not on
X5DLR-8G2)
• PS/2 mouse and PS/2 keyboard ports
• 4 USB (Universal Serial Bus) ports (USB 1.1)
Other
• Internal/external modem ring-on
• Recovery from AC power loss control
• Wake-on-LAN (WOL)
• Console redirection
• APM 1.2, DMI 2.1, PCI 2.2, ACPI 1.0, Plug and Play (PnP), SMBIOS 2.3
CD/Diskette Utilities
• BIOS flash upgrade utility
• Device Drivers
Dimensions
• Extended ATX: 12.05" x 13" (306 x 330 mm)
