Programming (Cont’d)
➻
10-03-13 : PCB Setup - Loss-of-Signal Detection Limit
Setup and confirm the Basic Configuration data for each PCB. Select the loss-of-signal detection limit.
In short-haul mode: 0=0.91V, 1=0.74V, 2=0.59V, 3=0.42V, 4=0.32V, 5=0.21V, 6=0.16V. 7=0.10V. In
long-haul mode: 0=1.70V, 1=0.84V, 2=0.84V, 3=0.45V, 4=0.45V, 5=0.20V, 6=0.10V, 7=not defined
➻ 10-03-14 : PCB Setup - Service Protocol for S-Point
Setup and confirm the Basic Configuration data for each PCB. Select the service protocol to be used
(0=keypad facility, 1=specified protocol for Aspire).
➻ 11-01-01 : System Numbering
Set up a Service Code for Alternate Trunk Route Access. You may want to use an alternate access code
for your outgoing PRI trunks. Also see programs 11-09-02 and 21-15-01.
Default Setting: No Alternate Trunk Route Access code programmed.
➻ 11-09-02 : Trunk Access Code - Alternate Trunk Route Access Code
Assign the Service Code set up in 11-01-01 for Alternate Trunk Route Access. You may want to use an
alternate access code for your outgoing PRI trunks. Also see programs 11-01-01 and 21-15-01.
Default Setting: No Alternate Trunk Route Access code programmed.
➻ 14-01-02 : Basic Trunk Data Setup - Transmit CODEC Gain Type
If required, adjust the transmit CODEC gains for each trunk.
Default Setting: 1 (0 dB transmit gain)
➻ 14-01-03 : Basic Trunk Data Setup - Receive CODEC Gain Type
If required, adjust the transmit CODEC gains for each trunk.
Default Setting: 1 (0 dB receive gain)
➻ 14-01-07 : Basic Trunk Port Setup - Outgoing Calls
Allow this option (1) for each PRI trunk you want to use for outgoing calls. Prevent this option (0) if
the trunk will not be used for outgoing calls.
Default Setting: Outgoing calls allowed (1).
➻ 14-01-10 : Basic Trunk Data Setup - DTMF Tones for Outgoing Calls
For each trunk, enable (1) or disable (0) DTMF tones for outgoing trunk calls.
Default Setting: DTMF tone disabled for outgoing calls (0).
➻ 14-05-01 : Trunk Groups
Assign the PRI trunks to trunk groups. This determines the channels available for PRI lines.
Default Setting: All trunks assigned to Trunk Group 1.
➻ 14-07-01 : Trunk Access Map Setup
Set up Trunk Access Maps (200) for PRI trunks. You must also assign extensions to Trunk Access
Maps in Program 15-06-01.
Default Setting: All trunks in Access Map 1 have full access (7). All trunks in the other Access
Maps have no access (0).
➻ 15-01-04 : Basic Extension Data Setup - ISDN Caller ID
If both Program 15-01-04 and 10-03-05 are enabled (1), the system includes Caller ID in the Setup
message as “Presentation Allowed”. If these options are disabled (0), it will be “Presentation
Restricted”.
