Quick Components Guide
Component Function Reference
CONN1/JPW1 Power connectors See p. 2-7
JKBMS1 Mouse connector See p. 2-8
JKBMS1 Keyboard connector See p. 2-9
USB Connectors Connecting to USB devices See p. 2-9
COMA & COMB/JCOM3 Serial port connectors See p. 2-10
RJ-45 LAN Jack Connecting to LAN devices See p. 2-11
LPT1 Parallel port connector See p. 2-12
FDD1 Floppy disk drive connector See p. 2-13
J8 Chassis intrusion switch connector See p. 2-13
IDE1 & IDE2 Hard disk connectors See p. 2-14
JCD1/JAUX1/JMD1 CD/AUX/Modem connectors See p. 2-15
CPUFA/SYSFA Fan power connectors See p. 2-16
JFP1 & JFP2 Front panel connectors See p. 2-17
JAUD Front panel audio connector See p. 2-18
JUSB2 & JUSB3 USB front connectors See p. 2-19
JIR IrDA infrared module connector See p. 2-20
JBAT1 Clear CMOS jumper See p. 2-25
AGP Slot Connecting to AGP cards See p. 2-26
PCI Slots Connecting to expansion cards See p. 2-26
CNR Slot Connecting to expansion cards See p. 2-26
JLAN LAN Active LED Jumper See p. 2-20
J1394_1 & J1394_2 IEEE 1394 Connectors See p. 2-21
JSP1 SPDIF Connector See p. 2-22
JMOD Modem Connector See p. 2-23
