6 Configuration via RS232
◗ Use the cord supplied with the card.
◗ Connect the card to a computer equipped with a hyperterminal type emulator. The serial link must be set at 9600
baud, 8 bits, no parity, 1 stop bit, and without flow control.
◗ Check that UPS power is on.
◗ Enter the MGEUPS or mgeups password (non modifiable).
◗ The menu is in English only.
-----------------------------------------------------------------------------
MGE UPS SYSTEMS
NETWORK MANAGEMENT CARD
-----------------------------------------------------------------------------
1 : Reset
2 : Network configuration
3 : Set Login Password to Default
4 : Return to Default Configuration
0 : Exit
-----------------------------------------------------------------------------
