Indicator Meaning
8 Battery status
Green:
The battery is charged between 80% to 100% of the capacity,
and being discharged between 20% to 80% of the capacity.
Blinking green:
The battery is charged between 20% to 80% of the capacity,
and being charged.
Orange:
The battery is charged between 5% and 20% of the capacity,
and being discharged.
Blinking orange (slow):
The battery is charged between 5% to 20% of the capacity,
and being charged.
Blinking orange (rapid):
The battery is charged between 0% to 5% of the capacity.
Note:
If the computer is operating on battery power, the battery
status indicator does not work while the computer is turned off
or hibernation mode.
9 Wireless status
Green:
The wireless feature (the IEEE 802.11 standard) is on, and the
radio link is ready for use.
Blinking green:
Data is being transmitted.
FRU tests
The following table shows the test for each FRU.
FRU Applicable test
System board 1. Diagnostics --> CPU/Coprocessor
2. Diagnostics --> Systemboard
LCD unit 1. Diagnostics --> Video Adapter
2. Interactive Tests --> Video
Keyboard 1. Diagnostics --> Systemboard --> Keyboard
2. Interactive Tests --> Keyboard
Hard disk drive Diagnostics --> Fixed Disks
Diskette drive v Diagnostics --> Diskette Drives
Memory 1. If two DIMMs are installed, remove one of them and run
Diagnostics --> Memory Test—Quick.
2. If the problem does not recur, return the DIMM to its place,
remove the other one, and run the test again.
3. If the test does not detect the error, run Diagnostics -->
Memory Test—Full.
