3-42
Catalyst 3750, 3560, 3550, 2975, 2970, and 2960 Switch System Message Guide
OL-8551-04
Chapter 3 Message and Recovery Procedures
FM Messages
Error Message FM-3-QOSTTABLE: Not in truth table: ACL [dec] in map, action [dec].
Note This message applies only to Catalyst 3550 switches.
Explanation A software error occurred while trying to merge a quality of service (QoS) policy map.
The first [dec] is the number in the policy map (counting from zero) of the particular ACL where the
problem was discovered, and the second [dec] is an internal code number for the result of matching
that ACL in the policy map.
Recommended Action Copy the message exactly as it appears on the console or in the system log.
Research and attempt to resolve the error by using the Output Interpreter. Enter the show
running-config user EXEC command to gather data that might help identify the nature of the error.
Use the Bug Toolkit to look for similar reported problems. If you still require assistance, open a case
with the TAC, or contact your Cisco technical support representative, and provide the representative
with the gathered information. For more information about these online tools and about contacting
Cisco, see the
“Error Message Traceback Reports” section on page 2-7.
Error Message FM-3-RELOADED: Reloading [chars] label [dec] feature in [chars].
Note This message applies only to Catalyst 3550 switches.
Explanation The feature manager is now able to fit more of the configured features on this label into
the hardware. One or more features had been previously unloaded because of a lack of space. The
first [chars] is the direction (input or output), [dec] is the label number, and the second [chars] is the
TCAM ID.
Recommended Action No action is required.
Error Message FM-3-TOSCOST: Minimize monetary cost TOS bit unsupported in hardware,
ignored.
Note This message applies only to Catalyst 3550 switches.
Explanation This hardware platform does not support filtering based on the type of service (ToS) and
precedence; it supports filtering based on Differentiated Services Code Points (DSCPs). The DSCP
field does not include the minimize monetary cost bit from the ToS field; the hardware ignores this
bit when checking for a match to an ACE, which can lead to unintended filtering actions.
Recommended Action Design filters that do not test for the minimum monetary cost ToS.
