2-11 The Command WorkStation interface
Server selection tabs
The Server selection tabs, just below the menu bar at the top of the display,
can be used to log in to additional iR C2100/2100Ss (if your site has more
than one) and to switch between iR C2100/2100Ss currently connected to
the Command WorkStation.
If you click a blank tab, you are prompted to connect to a iR C2100/2100S
in the list or configure a new iR C2100/2100S entry (see “Connecting to the
iR C2100/2100S” on page 2-3). A limit of five iR C2100/2100Ss can be
connected to a single Command WorkStation.
You can access the Server selection tabs from all Command WorkStation
windows (Queues, Archive, and Job Log).
Sliders
Along the left side of the display are buttons you click to activate function
sliders.
Window Filter Open the Filter dialog box for the active window;
see page 2-27.
Export Save the information in the active window as a tab-delimited
text file; see page 2-27.
Print Print the active window.
View in Helper App Open the active window in a particular application you specify;
see page 3-5.
Refresh Update the Job Log window with the latest information.
Revert to Default Settings Restore default settings for the status areas, the column
headings, and the column widths.
Help About View the Command WorkStation information screen.
Menu: Choose this: To do this:
