Port Configuration Menu
The Port Configuration Menu allows you to configure port settings for a
specific port. Select
c
from the Port Menu to view the Port Configuration
Menu. Figure 3-18 shows the Port Configuration Menu and the
accompanying table describes the Port Configuration Menu.
Figure 3-18. Port Configuration Menu
PORTS 1-5 CONFIGURATION Access Control: READ/WRITE
a Port Name
b. Port Enable Yes
c. Flow Control Enable No
d. Auto-negotiation Enable No
e. Full Duplex Yes
f. Port Speed 100
x. Previous Menu
Enter Selection:
Selection Description
Port Name Allows you to assi
n an administrative name to the port (1-14
character ran
e).
Port Enable Allows you to enable (Yes) or disable (No) the port(s).
Flow Control Enable Allows you to enable (Yes) or disable (No) flow control on the
port(s).
Auto-ne
otiation
Enable*
Allows you to enable (Yes) or disable (No) the auto-ne
otiation
mode for the port(s).
If Auto-ne
otiation Enable is set to “No,” the Full Duplex and
Port Speed fields display and are eli
ible for confi
uration.
If Auto-ne
otiation Enable is set to “Yes,” the Full Duplex and
Port Speed fields disappear and the system automatically man-
a
es these functions.
Full Duplex* Allows you to enable (Yes) or disable (No) the full duplex mode
for the port(s).
Port Speed* Allows you to set the speed (10 or 100Mbps) for the port(s).
* These parameters are not configurable for 100Base-FX ports, which only operate
in full duplex mode and at 100Mbps speed.
