4-3
LANVIEW LEDs
The status of the FNB Receive LED is listed in Table 4-4.
The status of the FNB Transmit LED is listed in Table 4-5.
The status of the ATM Receive LED is listed in Table 4-6.
Table 4-4. FNB Receive LED
LED Color State
Green Link exists, no activity, port is enabled
Yellow (Flashing) Link exists, activity, port is enabled
Red No link, port is disabled
Red (Flashing) Link exists, port is disabled
Off No link, no activity, port is enabled
Table 4-5. FNB Transmit LED
LED Color State
Green (Flashing) Activity, port is enabled
Yellow (Flashing) Port is in standby mode
Red Port is disabled
Red (Flashing) Fault or error exists
Off No activity, port is enabled
Table 4-6. ATM Receive LEDs
LED Color State
Yellow (Flashing) Activity
Red Failure
Off No Activity
