Vending
27
512686
Table 6 (continued)
Models Starting Serial No. 0909
Total Cycle Time = Heat Time + Cool Down Time
Table 6
Test Setting
When testing coin slide operation or other
troubleshooting, set dipswitch with this shorter cycle:
1. Unplug the machine power cord.
2. Record the machine control dipswitch settings.
Then set them all to the off position. Refer to
Figure 25.
3. Plug in the machine and initiate a cycle.
NOTE: With all the control dipswitches off, the
total cycle time will be four minutes long.
4. Once all the testing is complete, unplug the
machine and re-set the dipswitches to their
original settings.
5. Plug in the machine.
Figure 25
Cool Down Per Cycle
Cool Down
Switch Number
Cycle Reset
Switch Number
(in minutes)
78
3 (preset at factory)
OFF OFF
6
ON ON
DRY2225P
DRY2225P
1
2345678
O
N
