13
If cycle counter (9 0C) is selected, the following is true:
If money counter (1.0C or 1.C0) is selected, the following
is true:
END of SET-UP PROCEDURES.
EXIT FROM SET-UP MODE
PD Models: Reinstall access door.
PR Model: Remove manual set-up cards.
CODE EXPLANATION
J. Cd COIN/DEBIT OPTION
J.
J.
J.
J.
Cd
C_
_d
Ed
Both coin and debit selected. Press the QUICK
CYCLE button 3 consecutive times to change this
selection.
Coins selected, debit disabled. Press the QUICK
CYCLE button 3 consecutive times to change this
selection.
PR models factory default to J._d. Debit Card
selected, coins disabled. Press the QUICK CYCLE
button 3 consecutive times to change this
selection.
Enhanced Debit is self-selected when a
Generation 2 card reader is installed in the washer.
The Ed option cannot be manually selected or
deselected.
Press the DELICATES AND KNITS button once to
advance to next code.
L. 00 PRICE SUPPRESSION OPTION
This option causes the customer display to show
‘ADD’ or ‘AVAILABLE’ rather than the amount of
money to add. (Used mainly in debit installations.)
L.
L.
00
PS
Not Selected ‘OFF’.
PS Selected ‘ON’. Press the QUICK CYCLE button
once for this selection.
Press the DELICATES AND KNITS button once to
advance to next code.
n. CE CLEAR ESCROW OPTION
When selected, money held in escrow for
30 minutes without further escrow or cycle
activity will be cleared.
n.
n.
00
CE
Not Selected ‘OFF’.
Selected ‘ON’. Press the QUICK CYCLE button
once for this selection.
Press the DELICATES AND KNITS button once to
advance to next code.
r. 800 TOP SPIN SPEED RPM
r. 800
This can be selected from the following spin
speeds: 600 rpm, 750 rpm, 800 rpm, 1000
(displays as 999) rpm. Step between speeds by
pressing the PERM PRESS button. Factory default
of 800 rpm.
Press the DELICATES AND KNITS button once to
advance to next code.
U. 00 PENNY INCREMENT OFFSET
U. 00
This represents the penny increment price offset
used in Generation 2 (Enhanced Debit) PR models.
Choose from 0-4 pennies by pressing the PERM
PRESS button.
Press the DELICATES AND KNITS button once to
advance to next code.
A1. 00 PREWASH LENGTH
A1. 00
This is the number of minutes of PREWASH.
Choose 0 to disable the prewash or select between
2 and 7 minutes by pressing the PERM PRESS
button.
Press the DELICATES AND KNITS button once to
advance to next code.
CODE EXPLANATION
A2. 03 FINAL SPIN LENGTH
A2. 03
This is the number of minutes of final high speed
spin. Choose from 3-8 minutes by pressing the
PERM PRESS button.
Press the DELICATES AND KNITS button once to
advance to next code.
1 00 Number of cycles in
HUNDREDS
1 02
= 200
2 00 Number of cycles in ONES
2 25
=25
TOTAL CYCLES = 225
This is “VIEW ONLY” and cannot be cleared.
Press the DELICATES AND KNITS button once to advance to
next code.
3 00 Number of dollars in
HUNDREDS
301
= $100.00
4 00 Number of dollars in ONES 4 68 = $ 68.00
5 00 Number of CENTS. 5 75
= $ .75
Total = $168.75
