Start Operating Set-up
Before proceeding, it is worth noting that, despite all of the
options available, an owner can simply choose to uncrate a new
commercial washer, hook it up, plug it in, and have a washer that
operates.
Washers are preset at the factory for a 11-minute wash period
and 3 rinses (no extra rinse).
SET-UP CODES
The DELICATES AND KNITS button will advance from code to
code. The PERM PRESS button will change the code value. The
QUICK CYCLE button will select or deselect options.
FOR PR MODELS: The set-up codes are the same as for the
“PD” model except where noted.
The set-up code is indicated by the one or two left-hand
characters. The set-up code value is indicated by the two or
three right-hand characters.
Options to use if SPECIAL PRICING is selected.
CODE EXPLANATION
607 REGULAR CYCLE PRICE (Factory Default)
6
6
07
00
Represents the number of quarters (coin 1); may
adjust from 0-39. (See VALUE OF COIN 1.)
Advance from 0-39 by pressing the PERM PRESS
button. Factory default of 7 quarters = $1.75.
PR MODELS ONLY: Factory default of 0 quarters.
6 01 setting would represent one coin slide
actuation.
Press the DELICATES AND KNITS button once to
advance to next code.
711 WASH LENGTH
711
This is the number of minutes for WASH. Washer
comes from the factory preset with 11 minutes.
Choose from 9-17 minutes by pressing the PERM
PRESS button.
Press the DELICATES AND KNITS button once to
advance to next code.
NOTE: This option does not apply to QUICK
CYCLE.
800 ADDITIONAL RINSE OPTION
This option is either SELECTED ‘ON’ or NOT
SELECTED ‘OFF’.
8
8
00
Ar
Not Selected ‘OFF’.
Selected ‘ON’. Cannot be combined with the Super
Cycle rinse option.
Press the QUICK CYCLE button once for this
selection.
Press the DELICATES AND KNITS button once to
advance to next code.
900 CYCLE COUNTER OPTION
This option is either SELECTED ‘ON’ or
NOT SELECTED ‘OFF’.
9
9
00
0C
Not Selected ‘OFF’.
Selected ‘ON’ and not able to be deselected.
Press the QUICK CYCLE button 3 consecutive
times to select ‘ON’. Once selected ‘ON’ it cannot
be deselected.
Press the DELICATES AND KNITS button once to
advance to next code.
CODE EXPLANATION
1. 00 MONEY COUNTER OPTION
This option is either SELECTED ‘ON’ or NOT
SELECTED ‘OFF’.
1.
1.
1.
00
0C
C0
Not Selected ‘OFF’.
Selected ‘ON’.
Press the QUICK CYCLE button 3 consecutive
times to select ‘ON’ and 3 consecutive times to
remove (Not Selected ‘OFF’). Counter resets by
going from ‘OFF’ to ‘ON’.
Selected ‘ON’ and not able to be deselected. To
select ‘ON’ and not able to be deselected, first
select ‘ON,’ then within 2 seconds, press the
QUICK CYCLE twice, the PERM PRESS once, and
exit set-up mode.
Press the DELICATES AND KNITS button once to
advance to next code.
2. 00 SPECIAL PRICING OPTIONS
This option is either SELECTED ‘ON’ or NOT
SELECTED ‘OFF’.
2.
2.
00
SP
Not Selected ‘OFF’, and next available code
will be A.00
Selected ‘ON’. Press the QUICK CYCLE button
once for this selection.
If SPECIAL PRICING OPTION is selected, there is access to
codes ‘3.XX’ through ‘9.XX’.
Press the DELICATES AND KNITS button once to
advance to next code.
3. 07 SPECIAL CYCLE PRICE
3.
3.
07
00
Represents the number of quarters (coin 1); may
adjust from 0-39. (See VALUE OF COIN 1.)
Advance from 0-39 by pressing the PERM PRESS
button. Factory default of 7 quarters = $1.75
PR MODELS ONLY: Factory default of 0 quarters.
Press the DELICATES AND KNITS button once to
advance to next code.
5. 00 TIME-OF-DAY CLOCK, MINUTES
5. 00
This is the TIME-OF-DAY CLOCK, minute setting;
select 0-59 minutes by pressing the PERM PRESS
button.
Press the DELICATES AND KNITS button once to
advance to next code.
6. 00 TIME-OF-DAY CLOCK, HOURS
NOTE: Uses military time or 24 hr. clock
6. 00
This is the TIME-OF-DAY CLOCK, hour setting;
select 0-23 hours by pressing the PERM PRESS
button.
Press the DELICATES AND KNITS button once to
advance to next code.
7. 00 SPECIAL PRICE START HOUR
NOTE: Uses military time or 24 hr. clock
7. 00
This is the start hour; 0-23 hours. Select START
HOUR by pressing the PERM PRESS button.
Press the DELICATES AND KNITS button once to
advance to next code.
