Troubleshooting Procedures
!
WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testing requires power.
16026882 4 June 2006
RPL 16026127
©2006 Maytag Services
Will Not Start
• Plug cord into live electrical outlet. Check for
proper voltage.
• Check fuse or reset circuit breaker.
• Push any key to turn ‘ON’ the clothes washer
and press the Rotary Cycle Selector knob to
start the clothes washer.
• Close door and push the Rotary Cycle
Selector knob to start the clothes washer.
• Check to see if the clothes washer is in a pause,
soak or suds period in the cycle. Wait briefly
and it may start. If washer is in suds period,
“SudS” will display, instead of the time
remaining.
• Check for restricted drain system. If there is an
electrical problem in the drain system, “nd” error
will occur after 15 minutes.
• Check water supply.
• Check the line screen and water valve screen.
• Check for loose connections at machine control
board terminal connections CN5 and CN6 (See
“Component Testing Procedures”).
• Replace machine control board.
Leaking
• Make sure inlet hose connections are not
leaking. Check for rubber gasket damage due to
over-tightening.
• Check standpipe for leak. Wrap a dry rag
around the standpipe opening. If rag becomes
wet, leak is fault of home plumbing. Be sure the
standpipe is capable of accepting the incoming
flow of water from the clothes washer.
• Make sure end of drain hose is correctly
inserted and secured to drain standpipe.
• Check internal hose connections (fill, drain
systems, dispenser hoses & clamps).
• Check rubber boot. Remove, reposition and
reinstall, if necessary.
• Check for possible kinked dispenser to outer tub
hose. Hot water pressurization may force door
open.
No Tumble
• Start normal cycle with an empty machine and
allow a fill to check tumble.
• See Board Output Test, or Quick Spin Test
(Before test, make sure that the tumbler is
empty.)
• Check for loose connections at machine control
board, pressure switch, motor, tach harness and
motor control.
• Check motor windings resistance (See
“Component Testing Procedures”).
At CN9, pins 1 & 3 = 3.0 ohms.
Pins 1 & 2 = 3.0 ohms.
Pins 2 & 3 = 3.0 ohms.
• Check belt.
• Faulty main control board.
• Faulty motor.
Will Not Spin
• Check to make sure the door is fully closed.
• Check for water left inside the clothes washer. If
present, see Will Not Drain.
• See Board Output Test or Quick Spin Test.
(Before test, make sure that the tumbler is
empty.) If it doesn’t tumble after the test above,
check unbalanced load scenario, machine
control board, and motor.
• Check for loose connections at pressure switch,
motor, tach harness, motor control and machine
control board terminal connections CN8, CN9,
CN3 (See “Component Testing Procedures”).
• Check motor windings resistance (See
“Component Testing Procedures”).
At CN9, pins 1 & 3 = 3.0 ohms.
Pins 1 & 2 = 3.0 ohms.
Pins 2 & 3 = 3.0 ohms.
• Check belt.
No Water Fill
•
Test water fill. See Board Output Test.
• Check to make sure water supply is turned on
fully.
• Check electrical circuit and connections at the
water valve, and pressure switch.
• Check for kinks in inlet hoses.
• Check for clogged inlet screens.
• Visually check hot, cold, pre and bleach valves
separately for fill.
• Check for low water pressure. May be
dependent on pressure entering home.
Variations may occur due to usage in the home
at the time machine is used.
• Check for frozen pipes and hoses.
• Check resistance of water valve coils (See
“Component Testing Procedures”). Check pin
#2 of CN7 with pin #1, 2, 3 or 4 of CN10.
Normal is 1.18K ohms.
• Check for loose connections at the pressure
switch or on the machine control board at CN3.
(See “Component Testing Procedures”).
