113429-9 Telephone 01422 822282 29
!
!
Preoperational Instructions __________
Important
For more detailed information regarding the
microprocessor controller (computer), refer to the
microprocessor user’s manual included with the dryer.
Coin Models
Microprocessor Controller (Computer)
When the microprocessor controller (computer) is in the ready
state, the L.C.D. screen will display “Ready, Insert $XX.XX
(amount) to Start”.
Insert coin(s). Once the correct “Amount to Start” has been
inserted, the L.C.D. will display “Select Temperature”.
Select temperature by pressing “HI,” “MED,” or “LO.” The
cycle will start and the L.C.D. will display the Dry Cycle selected
and the remaining time.
The dryer will continue through the drying and cooling cycles,
until the vended time has expired.
Note
To stop the dryer, open main door. Continuation of
the cycle will resume only after the door has been
closed and any one of the 3 temperature selections is
pressed.
Non-Coin Models
Microprocessor Controller (Computer)
The L.E.D. display reads “READY” (no cycle in progress).
Press the letter on the keypad corresponding to the cycle
desired (e.g. key “D”).
The dryer will then start (i.e. blower, tumbler, and heat).
The L.E.D. display will read MANUAL DRYING CYCLE D,
___MIN REMAIN.
Note
The dryer can be stopped at any time by pressing
the “STOP/CLEAR” key, at this time the dryer will
go into a cycle pause. If the “STOP/CLEAR” key is pressed
again at this point, the cycle that was in progress will be
cancelled and returned to the “READY” state.
When the programmed drying time has expired, the non-coin
microprocessor controller (computer) will proceed into the
Cool Down Cycle.
Once the Cool Down Cycle begins at the end of the heat
cycle, the L.E.D. display will read COOL DOWN TEMP ___/
___ MINUTES remaining. At the end of the heat cycle, the
dryer will shut off the heat and continue the fan and tumbler
until the Cool Down Time or temperature is reached.
Shutdown Instructions ________________
If the dryer is to be shutdown (taken out of service) for a
period of time, the following must be performed:
Discontinue power to the dryer either at the external disconnect
switch or the circuit breaker.
Discontinue the heat supply:
Gas Models – Discontinue the gas supply.
Shut off external gas supply shutoff valve.
Shut off internal gas supply shutoff valve located in the gas
valve burner area.
Steam Models – Discontinue the steam supply.
Shut off external (location furnished) shutoff valves.
Service/Parts Information ____________
Service
Service must be performed by a qualified trained technician.
If service is required, contact the distributor from whom the
equipment was purchased. If the distributor cannot be
contacted or is unknown, contact the JLA Service Department
for a distributor in your area.
Note
When contacting the Service Department, be sure
to give them the correct model number and serial
number so that your inquiry is handled in an expeditious
manner.
Parts
Replacement parts should be purchased from the distributor
from whom the equipment was purchased. If the distributor
cannot be contacted or is unknown, contact the Parts
Department for a distributor in your area. Parts may also be
purchased directly from the factory by calling the JLA Parts
Department at 01422 822282 or you may FAX in your order at
01422 824390.
Note
When ordering replacement parts from the
distributor or the manufacturer, be sure to give
them the correct model number and serial number so that
your parts order can be processed in an expeditious
manner.
Warranty Information _________________
Returning Warranty Cards
Before any dryer leaves the factory test area, a warranty card
is placed on the inside of the main door glass. These
warranty cards are intended to serve the customer where we
record the individual installation date and warranty information
to better serve you should you file a warranty claim.
If a warranty card did not come with your dryer, contact the
JLA Warranty Department at 01422 822282.
Important
A separate warranty card must be completed and
returned for each individual dryer.
!
!
!
!
