© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Installation
803465
10
Risers
Risers (or air cushions) may have to be installed if the
pipes knock or pound when flow of water stops. The
risers are more efficient when installed as close as
possible to the water supply faucets (refer to
Figure 6).
Figure 6
Step 4: (Non-Gravity Drain Models Only)
Connect Drain Hose to Drain Receptacle
Remove the drain hose from its shipping position on
the rear of the washer by removing the shipping tape.
IMPORTANT: Drain receptacle must be capable of
handling a minimum of 1-3/8 inch (3.5 cm) outside
diameter drain hose.
Figure 7
W005I
1 Risers (Air Cushions)
2 Water Supply Faucets
W005I
2
1
FLW1963N
1 Shipping Tape
1
