Maintenance
15
F232134
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Weekly
1. Check the machine for leaks.
a. Start an unloaded cycle to fill the machine.
b. Verify that door and door gasket do not leak.
c. Verify that the drain valve is operating and
that the drain system is free from obstruction.
If water does not leak out during the first wash
segment, the drain valve is closed and
functioning properly.
Monthly
NOTE: Disconnect power to the machine at its
source before performing the monthly maintenance
procedures.
1. Use the following procedures to determine if
V-belt(s) require replacement or adjustment. Call
a qualified service technician in either case.
a. Check V-belt(s) for uneven wear and frayed
edges.
b. For groove-pulley drive systems, verify
alignment by placing a straightedge across
both pulley faces. The straightedge should
make contact with the pulleys in four places.
Refer to Figure 11.
Figure 11
c. For flat-pulley drive systems, verify allowable
distance of belt from edge of pulley. Refer to
Table 1 below.
H040I
1 Motor
2 Motor Pulley
3 Straightedge
4 Basket Pulley
H040I
1
2
3
4
Flat-Pulley Alignment
Model
Allowable
Distance from Edge
20 .09 in. (2 mm)
25 .09 in. (2 mm)
30 .09 in. (2 mm)
40 .09 in. (2 mm)
50 – 60 .38 in. (10 mm)
Table 1
