Operation
11
F232134
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
3. Load to capacity whenever possible. DO NOT
OVERLOAD. Refer to Figure 5.
NOTE: Underloading can cause out-of-balance
conditions that can shorten machine life.
Figure 5
4. Close door and turn handle counterclockwise
until button pops out. Refer to Figure 6.
Figure 6
5. Select wash cycle. Refer to Figure 7.
Figure 7
6. At start of cycle, add liquid and/or powder
supplies to supply dispenser. Refer to Figure 8.
a. Add detergent to container 1.
b. Add softener to container 3.
For non-coin models: Liquid supplies may be
injected directly into the supply dispenser by an
external chemical supply dispenser. Refer to
Installation and Programming Manuals.
U003IE1A
U005IE1B
U005IE1B
U002IE1A
S
P
I
N
CYCLE INDICATOR WASH CYCLES
P
R
E
W
A
S
H
W
A
S
H
R
I
N
S
E
ON
ADD BLEACH
WHEN LIT
HOT WARM WARM COLD
HEAVILY
SOILED
PERM-
PRESS
NORMAL
WASH
DELICATE
KNITS
To avoid personal injury, recommended
inlet water temperature should be no
higher than 125° Fahrenheit (51° Celsius).
W709
WARNING
