© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Basic Installation/Operation
13
F8321401 (EN)
125 Model
Table 5
CHM2279N
1 Dry Chemical Dispenser (Optional) 6 Hot Water Inlet
2 Input Power Block 7 Liquid Chemical Inlet
3 Fans 8 Steam Inlet (Optional)
4 Valve Panel 9 Drain Outlet
5 Cold Water Inlet
Figure 3
CHM2279N
125 POUND CAPACITY MACHINES
F
E
D
4
5
6
7
8
3
2
A
B
C
9
G
H
I
J
K
L
M
N
Q
P
O
1
Machine Capacity Dimensions for 125 Pound Models
A
78.8 in. (2002 mm)
J
61.28 in. (1557 mm)
B
14.62 in. (371 mm)
K
70.81 in. (1799 mm)
C
6.27 in. (159 mm)
L
50.2 in. (1275 mm)
D
29.56 in. (751 mm)
M
38.96 in. (990 mm)
E
41.28 in. (1049 mm)
N
35.74 in. (908 mm)
F
51.26 in. (1302 mm)
O
60 in. (1524 mm)
G
75.15 in. (1909 mm)
P
9.92 in (252 mm)
H
83.4 in. (2118 mm)
Q
88.09 in. (2237 mm)
I
2.86 in. (73 mm)
