© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Basic Installation/Operation
9
F8321401 (EN)
Table 2
Table 2 (Continued)
Variable-Speed and Fixed-Speed Models (Continued)
Specification 20 30 40 60 80 125
Cylinder Speeds
Gentle wash/reverse speed, RPM 292726262226
Wash/reverse speed, RPM 52 52 46 43 40 37
Distribution speed, RPM 92 92 82 77 70 65
Low extract speed, RPM 366 366 328 307 280 260
Medium extract speed, RPM
(Not available on Electronic Control models.)
534 534 478 447 408 378
High extract speed, RPM 686 686 613 574 524 485
Centrifugal Force Data
Gentle wash centrifugal force, Gs 0.25 0.25 0.25 0.25 0.25 0.43
Wash/reverse centrifugal force, Gs 0.8 0.8 0.8 0.8 0.8 0.8
Distribution centrifugal force, Gs 2.5 2.5 2.5 2.5 2.5 2.6
Low extract centrifugal force, Gs 40 40 40 40 40 40
Medium extract centrifugal force, Gs 85 85 85 85 85 85
High extract centrifugal force, Gs 140 140 140 140 140 140
Direct Steam Heating (Optional)
Steam inlet connection size,
in. (mm)
N/A N/A 1/2
(13)
1/2
(13)
1/2
(13)
3/4
(19)
Number of steam inlets N/A N/A 1 1 1 1
Steam required to raise bath water
temperature 10°F (6°C), lbs. (kg)
LOW N/A N/A 2.09
(0.94)
3.6
(1.63)
2.58
(1.17)
3.64
(1.65)
MED N/A N/A 2.40
(1.09)
4.4
(2.00)
4.65
(2.11)
5.17
(2.35)
HIGH N/A N/A 2.84
(1.29)
5.5
(2.50)
5.79
(2.63)
7.78
(3.52)
Average steam use per cycle, bhp (kg) N/A 0.73
(11.3)
1.43
(12.2)
2.32
(15.4)
1.34
(20.9)
1.14
(31.45)
Electrical Heating (Optional)
Total electrical heating capacity, kW
Input Voltage
200V 5.4 5.4 10.8 10.8 21.7 N/A
240V 7.8 7.8 15.6 15.6 31.2 N/A
380V 6.5 6.5 13.0 13.0 19.6 N/A
415V 7.8 7.8 15.5 15.5 23.3 N/A
480V N/A N/A 15.6 15.6 31.2 N/A
Electrical heating elements
333912N/A
Electrical heat element size, kW
2.6 2.6 5.2 2.6 2.6 N/A
