Changing-over the door stop
123
Changing-over the door stop
If the door stop does not suit the local conditions, it can be changed
over.
1
Warning! Before changing-over the door stop,disconnect the mains
plug; if the installation is permanent: Screw-out the fuse or switch-off
the circuit breaker.
Proceed as follows to change-over the door stop:
0 Unscrew screws A at the front of the appliance.
0 Remove the door by sliding it sideways.
0 Unscrew screws B on the inside of the door and remove hinges C.
0 Unscrew locking pin D and remove it.
0 Release covers E, F and G by pushing on the catch with a thin
screwdriver, push sideways, remove them and insert them on the
opposite side.
0 Screw hinges C and the locking pin D onto the opposite side of the
door.
G
J
G
J
F
A
C
B
E
D
E
F
H
A
C
B
