5. INSTALLING SOFTWARE DRIVERS
TR-824 User’s Manual
16
appears on screen then press <Enter>.
6. The Windows NT Setup window will appear again saying, “Setup will load support for the following
mass storage devices:” The list will include TR-824 SATARaid Controller for Windows NT 4.0 and
2000
NOTE: If there are any additional devices to be installed, specify them now. When all devices are
specified, continue to the next step.
7. From the Windows NT Setup screen, press <Enter>. Setup will now load all device files and then
continue the Windows NT installation.
8. After a successful installation, the SCSI Adapter Setup box will show that “the Tekram TR-824
SATARaid Controller driver has been installed”.
5.4.2 Existing Windows NT4.0 Installation
The following section details the installation of TR-824 drivers on a system that has Windows NT4.0
already installed and running.
NOTE: Do not attach the boot drive or any other hard drive to the TR-824 controller card before
completing this step.
1. From the Start menu, choose Settings.
2. From the Settings menu, choose Control Panel.
3. Double-click the SCSI Adapters icon. The SCSI Adapters dialog box appears.
4. Choose Drivers then click Add.
5. In the Install Drivers dialog box, click Have Disk….
6. When Install From Disk appears, insert the TR-824 driver diskette in drive A:\.
7. Type “A:\tr824.inf” in the text box window then click OK.
8. When the Install Driver dialog box appears, select Tekram TR-824 SATARaid Controller then click
OK.
9. When the Select SCSI Adapter Option dialog box appears, click Install.
10. After a successful installation, the SCSI Adapter Setup box will show that “the Tekram TR-824
SATARaid Controller has been installed”.
11. Power off your system.
12. If you plan to move the boot drive to the TR-824 card, connect the boot drive to the card now. Then
power on your system.
5.4.3 Removing the Driver from Windows NT4.0
1. From Start, choose Setup then choose Control Panel.
2. In Control Panel, choose SCSI Adapter then choose Drivers.
3. Click Remove.
4. After successful removal, the SCSI Adapter Setup box will show that “the Tekram TR-824
SATARaid Controller has been removed”.
5.5 Windows 98 Installation
5.5.1 New Windows 98 Installation
The following section details the installation of the TR-824 drivers while installing Windows 98.
1. Install the TR-824 controller card and configure the hard drive(s), partition and format your hard
drive(s), if necessary.
2. Install Windows 98 normally.
3. After installation, generate the Start menu and choose Settings.
4. From the Settings menu, choose Control Panel.
5. In the Control Panel window, double-click the System icon.
6. In the System window, choose the Device Manager tab.
7. In the hierarchical display under Other Device is a listing for PCI RAID Controller. Select it then click
the Properties button.
8. Choose the Driver tab in the Properties window, choose Update Driver then click
Next.
9.Choose Search for a better driver than the one your device is using now (recommended), then click
