5. INSTALLING SOFTWARE DRIVERS
TR-824 User’s Manual
13
5. INSTALLING SOFTWARE DRIVERS
5.1 Windows Server 2003 Installation
5.1.1 New Windows Server 2003 Installation
The following details the installation of the TR-824 drivers while Installing Windows 2003.
1. Start the installation:
• Floppy Install: Boot the computer with the Windows Server 2003 installation diskettes.
• CD-ROM Install: Boot from the CD-ROM. Press <F6> when the message “Press F6 if you need to
install third party SCSI or RAID driver” appears.
2. When the Windows Server 2003 Setup window is generated, press <S> to specify an Additional
Device(s)
3. Insert the TR-824 driver diskette into drive A:\ and press <Enter>.
4. Choose Tekram TR-824 SATARaid Controller for Windows XP/ Server 2003 from the list that
appears on screen, and then press <Enter>.
5. The Windows Server 2003 Setup screen will appear “Setup will load support for the following mass
storage devices:”. The list will include Tekram TR-824 SATARaid Controller for Windows XP/
Server 2003.
NOTE: If there are any additional devices to be installed, specify them now. When all devices are
specified, continue to the next step.
7. From the Windows Server 2003 Setup screen, press <Enter>. Setup will now load all device files and
then continue the Windows Server 2003 installation.
5.1.2 Existing Windows Server 2003 Installation
After installing the TR-824 card and rebooting your system, Windows Server 2003 setup will show a
Found New Hardware dialog box. Under Windows Server 2003, “RAID Controller” will be displayed.
1. Insert the TR-824 driver diskette into the drive A:\.
2. Choose install from a list or specific location and specify to search removable media then press
<Enter>.
3. Choose Tekram TR-824 SATARaid Controller from the list that appears on screen, and then press the
<Enter> key.
4. If using a driver that has not been digitally signed by Microsoft, you will be asked if you want to
continue the installation. Click Continue.
5. When the New Hardware Wizard has finished installing the TR-824 software, click Finish.
5.1.3 Confirming Windows Server 2003 Driver Installation
1. Right-click the My Computer icon and select Manage from the popup menu.
2. Click Device Manager in the menu tree.
3. Click the “+” in front of SCSI controllers. “Tekram TR-824 SATARaid Controller” should appear.
5.2 Windows XP Installation
5.1.1 New Windows XP Installation
The following details the installation of the TR-824 drivers while Installing Windows XP.
1. Start the installation:
• Floppy Install: Boot the computer with the Windows XP installation diskettes.
• CD-ROM Install: Boot from the CD-ROM. Press <F6> when the message “Press F6 if you need to
install third party SCSI or RAID driver” appears.
2. When the Windows XP Setup window is generated, press <S> to specify an Additional Device(s)
3. Insert the TR-824 driver diskette into drive A:\ and press <Enter>.
4. Choose Tekram TR-824 SATARaid Controller for Windows XP/ Server 2003 from the list that
appears on screen, and then press <Enter>.
5. The Windows XP Setup screen will appear “Setup will load support for the following mass storage
devices:”. The list will include Tekram TR-824 SATARaid Controller for Windows XP/ Server
2003.
NOTE: If there are any additional devices to be installed, specify them now. When all devices are
